Reusable Silicone Ventilator Circuits
Reusable silicone ventilator circuit configurations in adult, pediatric and neonatal sizes.
Reusable Silicone Ventilator Circuits
Reusable silicone ventilator circuit configurations in adult, pediatric and neonatal sizes.
Features and options
- A: 4 tubes, 1 Y-connector, 1 elbow connector with Luer cap and 2 water traps.
- B: extra limb, 0.2-3 m; C: breathing bag, 0.5/1/2/3 L; E: anesthesia mask.
- Optional catheter mount, sampling line, water trap and other listed accessories.
Model configurations
| REF No. | Size | Tube ID | Table length | Configuration |
|---|---|---|---|---|
| 06.826 | Adult | 22 mm | 0.2-3 m; custom lengths | A: 1 set |
| 30.040 | Adult | 22 mm | 0.2-3 m; custom lengths | A: 1 set + C |
| 30.043 | Adult | 22 mm | 0.2-3 m; custom lengths | A: 1 set + E |
| 30.046 | Adult | 22 mm | 0.2-3 m; custom lengths | A: 1 set + C + E |
| 30.049 | Adult | 22 mm | 0.2-3 m; custom lengths | A: 1 set + B + C + E |
| 06.827 | Pediatric | 15 mm | 0.2-3 m; custom lengths | A: 1 set |
| 30.041 | Pediatric | 15 mm | 0.2-3 m; custom lengths | A: 1 set + C |
| 30.044 | Pediatric | 15 mm | 0.2-3 m; custom lengths | A: 1 set + E |
| 30.047 | Pediatric | 15 mm | 0.2-3 m; custom lengths | A: 1 set + C + E |
| 30.050 | Pediatric | 15 mm | 0.2-3 m; custom lengths | A: 1 set + B + C + E |
| 06.828 | Neonate | 10 mm | 0.2-3 m; custom lengths | A: 1 set |
| 30.042 | Neonate | 10 mm | 0.2-3 m; custom lengths | A: 1 set + C |
| 30.045 | Neonate | 10 mm | 0.2-3 m; custom lengths | A: 1 set + E |
| 30.048 | Neonate | 10 mm | 0.2-3 m; custom lengths | A: 1 set + C + E |
| 30.051 | Neonate | 10 mm | 0.2-3 m; custom lengths | A: 1 set + B + C + E |
